BOA-Ku09 v2

  • Description
  • Parameters
  • Downloads

Broadband double reflector antenna with a omni directional kind of “barrel”. Purpose – send and receive signals at the central stations broadcasting, interactive microwave systems.

ParameterValue
Frequency range, GHz 10-14
Gain, dB 16.0
VSWR 1.5
Polarization Linear
HPBW (vertical), deg
Input power, kW 1
Waveguide WR-75 or С-120
Temperature range, °C -40 to +80
Humidity 100%
Dimensions, mm 100
Weight: 35
Allowable wind speed, mps 40
Casing material Radio transparent plastic
Mount Mounting on a horizontal surface
