IRD CRT1082IPE
- Description
- Parameters
- Downloads
Integrated Receiver Descrambler (IRD) is a compact size 8-channel head-end with 8 CI slotes for channels descrambling
| DVB-S2 receiver | |
|---|---|
| Number of channels | 8 |
| Receiving frequency range | 950-2150 MHz |
| Input signal level | -65-25 dBm |
| Nominal RF input impedance | 75 Ohm |
| Connector type | I EC, F-type |
| Modulation | QPSK, 8PSK, 16APSK |
| Symbol Rate | 1 -45Msps(QPSK,8PSK), 1 -36Msps(16APSK) |
| FEC | 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 6/7, 7/8, 8/9, 9/10 |
| Common Interface | |
| Number of channels | 8 |
| Specification | EN50221, ETSI TS 101699 |
| DVB-ASI Output | |
| Number of channels | 8 |
| Specification | EN 50083-9 |
| Output impedance | 75 Ohm |
| Connector type | IEC 169-8, BNC-type |
| Operation modes | Packet, 188 byte |
| Maximum output bit rate | 213 Mbps |
| DVB-over-IP | |
| Specification | ETSI TS 102034 |
| Streaming protocols | RTP, UDP |
| Number of multicast streams | 64 (SPTS) |
| Number of unicast connections | 8 (MPTS) |
| Network interface | 1Gbit Ethernet |
Taking into consideration that we (ROKS PrJSC) are developer and system integrator, also do not stop on our technical growth and improvement, know that view of all our devices and equipment including their technical parameters may be different from pictures presented on website and parameters listed on each device webpage.
Note! All details customer has to confirm in advance during ordering and before payment. Those parameters that were not specified and / or were not agreed while ordering will be implemented as basic at the discretion of the manufacturer. Each our customer has 1.5 year warranty and 7 year aftersales support for whole range of our products.
